ABB CL Series User Manual

Technical data
401
1SVC 440 795 M1100
Analog inputs
Number 4
Electrical isolation
To supply voltage No
To the digital inputs No
To the outputs
Yes
To the CL-NET network Yes
Type of input DC voltage
Signal range V DC 0 to 10
Resolution, analog V 0.01
Resolution, digital Bit 10
Value 0 to 1023
Input impedance kO 11.2
Accuracy
Two display system devices, of actual value % g 3
Within a unit, from actual value (I7, I8, I11, I12) % g 2
Conversion time, analog/digital
Debounce ON ms 20
Debounce OFF
Each cycle time
Input current mA < 1
Cable length (shielded) m 30
CL-LDR…, CL-LDT…

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
