Installation
40
1SVC 440 795 M1100
Mounting the display I/O module onto the display
base module
Figure: 18: Fitting the display I/O module
Figure: 19: Display base with display I/O module
h
The display I/O module can be mounted onto the fixing
shaft before or after the display base module is mounted.
