ABB CL Series User Manual

Installation
52
1SVC 440 795 M1100
AC display system
Figure: 34: Connecting inputs
N
> 1 A
L
I1
I3 I4
I7 I8
1 > 79 V
0 < 40 V
264 V
I1 – I12 0.5 mA 230 V h
I2 I5 I6
I9
I10
N
N
I11
I12
L
N
N
I1 – I12 0.25 mA 115 V h
0.6 x 3.5 x 100
U
e
= 115/230 V h 50/60 Hz
(85 – 264 V h)
I
e
= 150 mA
Warning!
The AC display I/O modules must only be used with the
devices CL-LDC.LAC2 and CL-LDC.LNAC2. Other devices
may be destroyed.

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
