Connecting high-speed counters and frequency
generators
High-speed counter signals on the display system can be
counted correctly on inputs I1 to I4 independently of the
cycle time.
Figure: 43: High-speed counters, frequency generators
L01–
> 1 A
L01+
I1 I3 I4 I7 I8 I9 I10
L02+
I2 I5 I6 I11 I12
+24V 0V 0V
