6253 DC Voltage Current Source/Monitor Operation Manual
5.8.4 TER? Command
5-49
5.8.4 TER? Command
The TER? command reads out the self set results.
1. Command response
2. Descriptions of values a, b, c, d and e
The TER register column in Table 4-18 shows the error factors and register values for a, b, c, d and e.
For example, an error in VSVM 3 V +FS of the self test is returned as follows.
00000, 00000, 00016, 00000, 00000
Calculation Comparator
calculation
upper and
lower limit
values
KH
±<data1>
UNIT,
±<data2>
UNIT
<data1>UNIT: upper limit
0Yes
<data2>UNIT: lower limit
0
UNIT: UV,MV,V,UA,MA,A
*4
KH? Response: KH±<data1>UNIT, KH±<data2>UNIT
data1... current or voltage upper limit
value
data2... current or voltage lower limit
value
<d.dddddE±d>
UNIT: V or A
The current or voltage value is returned depending
on the measurement function.
Yes Yes
*4: The setting range is from 0 to ±999.9999E+24.
Item Command Description
Default Operation possibility
Power
ON
Factory
shipment
DC/pulse
OPR/SUS
Sweep
OPR/SUS
ddddd,ddddd,ddddd,ddddd,ddddd
a
b
c
d
e
