6253 DC Voltage Current Source/Monitor Operation Manual
8.1 Source and Measurement
8-7
Overshoot: 5 % or less under pure resistance load and at the standard cable end
(3 A, 30 A and 300 A ranges excluded)
Line regulation: 0.003% of range or less
Load regulation: Voltage source: ±0.003% of range or less (by 4-wire connection and under
the maximum load)
Current source: Depending on the accuracy CMV error (A Vo / 1 V )
Output resistance: By 4-wire connection (Output cable not included)
Maximum load capacitance: Maximum load capacitance that does not generate oscillation in voltage
source or voltage limit status
Supplied cable resistance: 100 m or less
Maximum inductive load: Maximum inductive load that does not generate oscillation in current source
or current limit status
Output resistance ()
Maximum load
capacitance
Current range Voltage source Current source
3 A3 or less 10 G or higher 1 F
30 A500 m or less 1000 M or higher 1 F
300 A100 m or less 1000 M or higher 1 F
3 mA 10 m or less 100 M or higher 100 F
30 mA 10 m or less 10 M or higher 100 F
300 mA 10 m or less 1 M or higher 2000 F
2 A 10 m or less 100 k or higher 2000 F
Current source range/
current limit range
3 A, 30 A300 A 3 mA to 2 A
Response
Maximum inductive load FAST 100 H200 H 500 H
SLOW 100 H500 H1 mH
To Next Page
