6253 DC Voltage Current Source/Monitor Operation Manual
2.6.2 Menu Structure and Parameter List
2-26
1) Slope Cnt Number of slopes of the Multi-slope linear sweep When selecting MLinear
2 to 4
2) 1st Value 1st value of the Multi-slop linear sweep When selecting MLinear
VS IS
-110.000 V to +110.000 V +0.00000 A to 2.00000 A
3) 2nd Value 2nd value of the Multi-slop linear sweep When selecting MLinear
VS IS
-110.000 V to +110.000 V +0.00000 A to 2.00000 A
4) 3rd Value 3rd value of the Multi-slop linear sweep When selecting MLinear
VS IS
-110.000 V to +110.000 V +0.00000 A to 2.00000 A
5) 4th Value 4th value of the Multi-slop linear sweep When selecting MLinear
VS IS
-110.000 V to +110.000 V +0.00000 A to 2.00000 A
6) Last Value
Last value of the Multi-slop linear sweep When selecting MLinear
VS IS
-110.000 V to +110.000 V +0.00000 A to 2.00000 A
7) Step1 Value
1st step value of the Multi-slop linear sweep When selecting MLinear
VS IS
000.001 mV to 110.000 V 0.00001 A to 2.00000 A
8) Step2 Value
2nd step value of the Multi-slop linear sweep When selecting MLinear
VS IS
000.001 mV to 110.000 V 0.00001 A to 2.00000 A
9) Step3 Value
3rd step value of the Multi-slop linear sweep When selecting MLinear
VS IS
000.001 mV to 110.000 V 0.00001 A to 2.00000 A
10) Step4 Value
4th step value of the Multi-slop linear sweep When selecting MLinear
VS IS
000.001 mV to 110.000 V 0.00001 A to 2.00000 A
11) Bias Value Sweep bias value
VS IS
-110.000 V to +110.000 V +0.00000 A to 2.00000 A
12) PSW Base Pulse sweep base value
VS IS
-110.000 V to +110.000 V +0.00000 A to 2.00000 A
MENU
3) Sweep Value
Category Edit (Input/Run level)Select
