6253 DC Voltage Current Source/Monitor Operation Manual
3.2.1 MENU Key (Parameter Setting)
3-9
7) Store Sets the measurement data memory-related parameters.
Store Mode Selects the measurement data memory functions.
The data in the measurement data memory are cleared when the
Store Mode is changed.
Normal: Stores data in the measurement data memory in the
Normal mode.
Burst: Stores data in the measurement data memory in the
Burst mode. Used for high-speed measurement.
OFF: Turns OFF the measurement data memory storage
operation.
Memory Clear Clears data in the measurement data memory.
Press the ENTER key to run.
Memory View Displays the measurement data memory.
Top Adr: Displays and sets the top address.
Soft key PageUp Scrolls up one page.
Soft key PageDown Scrolls down one page.
8) Compute Set the calculation-related parameters.
Compare SW Switches the comparator calculation ON or OFF.
ON: Executes the comparator calculation.
The calculation result is reflected on the comparator
calculation indicator, the header of remote output data
and the status byte. The CMP indicator goes ON.
HI: High value < Measurement data
GO: Low value ≤ Measurement data ≤ High value
LO: Measurement data < Low value
OFF: Turns OFF the comparator calculation.
Scaling SW Switches the scaling calculation ON or OFF.
ON: Executes the scaling calculation.
The MATH indicator goes ON.
OFF: Turns OFF the scaling calculation.
Max/Min SW Switches the MAX/MIN calculation ON or OFF.
ON: Executes the MAX/MIN calculation.
The MAX indicator goes ON.
OFF: Turns OFF the MAX/MIN calculation.
Scaling Calculation =
(Measurement value) – Constant B
Constant A
Constant C
