• Shortest path. The tube head unit moves along the shortest possible
path to the target position. The positioning time is reduced. However,
more care must be taken to ensure that there are no extraneous objects
are in the lower area of the room.
• Safest path. The tube head unit first moves up, then horizontally and
then down to the target position. The positioning time is longer. Most
extraneous objects that may be present in the room are avoided.
This setting is configurable by service.
A short double beep indicates that position is reached.
Related Links
Automatic positioning button on page 32
Selecting an automatic position
The automatic positions are configured by the service engineer and cannot be
changed by the user.
To select another predefined automatic position:
1. Set the correct modality position.
2. Display the position screen.
Figure 70: Positioning controls
3. Click the up or down arrow next to the illustration of selected position
until the correct position is displayed.
Figure 71: Software console
Figure 72: Tube head display
The system can be moved to the selected automatic position.
164
| DR 600 | Software Console and Tube Head Display
3261K EN 20210708 0808
