Moving the system to parking position
The parking position is defined during installation and cannot be changed by
the user.
The parking position is intended as a position where the system can remain for
longer time, e.g. over night, when it is switched off. Typically the tube head
unit is moved towards a corner or over the radiographic table and the wall
stand bucky is moved to vertical position so they are out of the way for other
activities.
The parking position can be selected on tube head display only and applied
without involvement of the NX workstation.
To move system to parking position:
1. Display the position screen.
On the main screen of the tube head display, click the Positioner button.
2. Press parking button.
The parking position settings are loaded.
3. Press and hold the automatic positioning button.
A short double beep indicates that position is reached.
Related Links
Automatic positioning button on page 32
Moving the system to cleaning position
The cleaning position is defined during installation and cannot be changed by
the user.
The cleaning position is intended as a position the system allows best access to
all components for cleaning purposes. Typically the tube head unit is moved in
middle of the room so user can access them easily from all sides for cleaning.
The radiographic table and the wall stand are typically moved to a mid
position.
The cleaning position can be selected on tube head display only and applied
without involvement of the NX workstation.
To move system to cleaning position:
1. Display the position screen.
On the main screen of the tube head display, click the Positioner button.
2. Press cleaning button.
DR 600 | Software Console and Tube Head Display | 165
3261K EN 20210708 0808
