3-28 Agilent 4155B/4156B User’s Guide Vol.2, Edition 5
Measurement Functions
Standby Function
Available Units and Output Values
Following table shows the output value of the standby channels in the standby state.
The specified values are the values that are set on the MEASURE setup screens.
Output Values of non-Standby Channels
Following table shows the output value of non-standby channels in the standby
state.
FCTN MODE
Unit
a
a. VMUs and GNDU cannot be set to the standby channel.
SMU VSU PGU
VA R 1
VA R 2
VA R 1 ’
VSTARTSTART -
ISTART - -
VPULSE BASE - -
IPULSE BASE - -
CONST V SOURCE SOURCE SOURCE
ISOURCE - -
VPULSE BASE -
Specified pulses.
b
b. Pulses as defined in MEASURE: PGU SETUP screen. If both PGUs are
set to VPULSE, the STBY settings of both PGUs must be same.
IPULSE BASE - -
Function of Unit Output Value Range
Voltage Output 0 V Output Range used in the
previous state.
Current Output Output value in the
previous state.
a
a. outputs the latest value of previous state. For example, if previous state
was measurement state and latest value of VAR1 was stop value, the
stop value is output for VAR1 during standby.
Voltage Measurement - Output Range used in the
previous state.
Current Measurement -
