Agilent 4155B/4156B User’s Guide Vol.2, Edition 5 3-51
Measurement Functions
R-BOX Control
Circuit Diagram
Figure 3-8 shows a simplified circuit diagram of an 16441A R-Box.
Table 3-4 shows switching conditions for each setting.
Table 3-4 Switching Conditions of the 16441A R-Box
Resistance is switched before and after measurement state. In the standby state, the
stress state, and the idle state, 0 W is connected.
Settings
Switches
SW1 SW2 SW3 SW4
0 W ON ON OFF OFF
10 kW OFF OFF OFF ON
100 kW OFF OFF ON OFF
1 MW OFF OFF OFF OFF
