4-26 Agilent 4155B/4156B User’s Guide Vol.2, Edition 5
Making a Measurement
Sweep Measurements
To Use Standby Function
1. Press Chan key in the PAGE CONTROL key group.
2. Select CHANNEL DEF primary softkey.
3. In the STBY column of the desired unit, select STANDBY ON secondary
softkey.
4. Press Standby key in the MEASUREMENT key group.
The indicator above the Standby key shows whether the Standby function is
enabled. If this indicator is ON, then for the units that you selected STANDBY ON,
the units have the following output value during the Standby state (that is, before
and after measurements or stress):
For sampling measurements, only the CONSTANT function is available.
From Standby state, you can execute measurements or force stress by pressing
Single, Repeat, Append, or Stress key. After measurement or stress, the STANDBY
ON units are returned to same output value as before measurement or stress.
If Standby indicator is ON, then pressing the Standby key disables the Standby
function, and Standby output stops. Pressing the Stop key has no affect on the
Standby state.
Function of a Unit Output during Standby State
VAR1 VAR1 Start value
VAR1' Ratio ´ Start + Offset
VAR2 VAR2 Start value
CONSTANT Output value
To Next Page
