3-12 Agilent 4155B/4156B User’s Guide Vol.2, Edition 5
Measurement Functions
Knob Sweep Function
Normal Sweep and Knob Sweep Measurements
Table 3-3 compares the normal sweep measurement performed by measurement
front-panel keys and knob sweep measurement by the front-panel knob.
Table 3-3 Comparison of Sweep Measurement and Knob Sweep Measurement
a
Measurement range is automatically set according to specified compliance value.
b
Settings on the MEASURE: OUTPUT SEQUENCE screen also apply to knob
sweep measurement.
Item Sweep Measurement Knob Sweep Measurement
Spacing of VAR1 linear or log linear
Sweep Mode of VAR1 single or double single or double
Number of Steps for VAR1 1 to 1001 1 to 1001
Hold Time 0 to 655.35 s 0 to 655.35 s
Power Compliance available not available
Measurement Ranging Mode auto, limited auto, or fixed
compliance range
a
Standby Function available available
Measurement Channel 1 to 8 ch 1 ch only
Output Sequence can set
can set
b
Trigger Function available not available
Integration Time short, medium, or long 80 ms
