Making a Measurement
Sweep Measurements
Sweep Measurements
This section describes the sweep measurement tasks.
The basic procedure to test your DUT is as follows:
1. Connecting your DUT to the
4155B/4156B. See “Connecting DUT” on
page 4-3 for procedures.
2. Defining measurement mode and
measurement units that you use to make
measurement.
The following tasks are described:
•“To Define Measurement Units”
•“To Define a User Function”
•“To Use R-Box”
3. Setting the source parameters of the
units. The following tasks are described:
•“To Set up Primary Sweep”
•“To Set up Secondary Sweep”
•“To Set up Synchronous Sweep”
•“To Set up Constant Output”
•“To Set up SMU Pulsed Output”
•“To Set up PGU Output”
