6-16 Agilent 4155B/4156B User’s Guide Vol.2, Edition 5
Screen Organization
MEASURE Screen Group
MEASURE Screen Group
MEASURE screen group has the following screens:
Sweep Setup or
Sampling Setup: For setting the parameters for sweep or sampling measurement,
which was defined in the CHANNELS: CHANNEL
DEFINITION screen.
PGU Setup: For setting the PGU parameters. This screen is available when
PGU is installed and the MODE and FCTN field of PGUs are
set on the CHANNELS: CHANNEL DEFINITION screen.
Measure Setup: For setting the measurement range, integration time, zero
cancel, and wait time.
Output Sequence: For setting the output sequence and triggering.
To move into the MEASURE screen group, press Meas front-panel key. The
following primary softkeys appear:
SWEEP PGU MEASURE OUTPUT PREV NEXT
SETUP
SETUP SETUP SEQ PAGE PAGE
or
SAMPLING PGU MEASURE OUTPUT PREV NEXT
SETUP
SETUP SETUP SEQ PAGE PAGE
• Select SWEEP SETUP softkey to move to MEASURE: SWEEP SETUP screen.
• Select SAMPLNG SETUP softkey to move to MEASURE: SAMPLING
SETUP screen.
• Select PGU SETUP softkey to move to MEASURE: PGU SETUP screen.
• Select MEASURE SETUP softkey to move to MEASURE: MEASURE SETUP
screen.
• Select OUTPUT SEQ softkey to move to MEASURE: OUTPUT SEQUENCE
screen.
