Agilent 4155B/4156B User’s Guide Vol.2, Edition 5 6-7
Screen Organization
CHANNELS Screen Group
NOTE Application setup data in internal memories
MEM secondary softkeys indicate that setup or measurement result data is in the
internal memory. When you turn on the 4155B/4156B without a diskette or network
disk, the following secondary softkeys are displayed:
MEM1 M
B-Tr VCE-IC measurement setup data for bipolar transistor Vce-Ic
characteristics.
MEM2 M
FET VDS-ID measurement setup data for FET (field effect transistor) Vds-Id
characteristics.
MEM3 M
FET VGS-ID measurement setup data for FET (field effect transistor) Vgs-Id
characteristics.
MEM4 M
DIODE VF-IF measurement setup data for diode Vf-If characteristics.
M on the softkey means measurement setup data.
Select softkey to get the desired application measurement setup data. This
eliminates the time required to set the setup screens.
See "Initial Settings" in User's Guide General Information.
