Screen Organization
GRAPH/LIST Screen Group
MARKER softkey
Select MARKER primary softkey to display secondary softkeys for operation with
marker.
• MARKER softkey
Select MARKER secondary softkey to toggle marker display between ON and
OFF. When ON is displayed on this softkey, the row at marker location is
highlighted. When OFF is displayed on this softkey, no row is highlighted.
The marker on the GRAPH/LIST: LIST screen is linked to marker on the
GRAPH/LIST: GRAPHICS screen. So, if marker is moved on the
GRAPH/LIST: GRAPHICS screen, the marker also moves on the
GRAPH/LIST: LIST screen.
The 4155B/4156B remembers the location of marker. So, if you turn marker
display OFF, then the marker appears at the same location when you turn marker
ON again.
• DIRECT MARKER softkey
Select DIRECT MARKER secondary softkey to move the marker to the
specified value directly. When you select this softkey, a cell marker is displayed
in the row of the marker, and the primary and secondary softkeys change as
follows:
Primary softkeys:
EXIT CANCEL
Secondary softkeys:
MARKER SEARCH MARKER
MIN/MAX MORE SKIP
In this mode, you can move the marker to a specified value. You enter the value
in the data entry area, then the marker moves to the value in list that is closest to
the specified value. If you have executed append measurement, the marker
moves within the append measurement you refer to.
You use the cell marker to specify the target variable (column). You can move
this marker by using the left arrow, up arrow, right arrow, and down arrow
MARKER/CURSOR keys.
Selecting EXIT primary softkey exits the DIRECT MARKER function.
Selecting CANCEL primary softkey returns the marker to the same position as
before selecting the DIRECT MARKER secondary softkey.
