How to clean connectors Cleaning Instructions

Agilent 8163A/B, 8164A/B & 8166A/B Mainframes, Sixth Edition 435

An Alternative Procedure

A better, more gentle, but more expensive cleaning procedure is to use an

ultrasonic bath with isopropyl alcohol.

1 Hold the tip of the connector in the bath for at least three minutes.

2 Take a new, dry soft-tissue and remove the alcohol, dissolved sediment and

dust, by rubbing gently over the surface using a small circular movement.

3 Blow away any remaining lint with compressed air.
