Getting Started How to Change the Value of a Parameter

58 Agilent 8163A/B, 8164A/B & 8166A/B Mainframes, Sixth Edition

How to Set All Parameters to Their Default

Values

Press Preset to set all parameters to their default values.

If You Make a Mistake

If you make a mistake while you are editing a parameter, you can cancel

the editing, and retain the previous value for the parameter by pressing the

[Cancel] softkey.

If the Parameter Changes to Different Value

If you press Enter or the [OK] softkey and the parameter changes to a

different value, then you tried to enter a value outside the calibrated range.

The new value is the nearest valid value to the value you entered.
