How to Get Information About Modules

To get information about modules:

1 Press the Config hardkey.

2 Move to the <About Modules> menu option and press Enter. You see a box

displaying the slots which have installed modules, see Figure 37 .

Figure 37 Slots with Installed Modules

3 Move to the module using the cursor key for which you require information.

Press Enter.

4 The part number, serial number, and firmware revision of the chosen module

are displayed, as shown in Figure 38 .
