188 Chapter4
Key Function Descriptions
Key Function Tables
AMPCOR MENU CAL
Accesses functions that allow you to enter amplitude
correction (ampcor) factors to correct system flatness.
AMPCOR ON OFF CAL
Turns the amplitude correction factors on and off.
When this mode is selected, a W appears on the left side
of the display.
AMPTD CORRECT AUX CTRL
Accesses functions that set conversion loss and
flatness data for external mixer measurements.
ANALOG METHOD MEAS/USER
Makes adjacent channel power (ACP) measurements
by measuring continuous power integration versus
frequency.
ANALYZER ADDRESS CONFIG
Displays the current GPIB address of the spectrum
analyzer.
AUX CTRL —
Accesses a menu of tracking generator, internal mixer,
external mixer, demodulation, and rear-panel
functions.
AVERAGE CNV LOSS AUX CTRL
Displays the mean conversion loss for the current
harmonic and allows you to enter new conversion loss
data.
AVG "OFF" POWER MEAS/USER
Measures the power of the carrier when the burst is
off.
AVG "ON" POWER MEAS/USER
Measures the power of the carrier when the burst is
on.
BW CONFIG
Selects a monochromatic printer configuration for use
with COPY.
BIAS AUX CTRL
Displays a menu of functions for selecting
external-mixer bias for unpreselected external mixers.
BIAS OFF AUX CTRL
Turns external mixer bias off.
BURST/WEIGHTNG MEAS/USER
Accesses functions that allow you to change the burst
width and period for ACP measurements.
BURST PERIOD MEAS/USER
Sets the burst period for ACP measurements.
BURST WIDTH MEAS/USER
Sets the burst width for ACP measurements.
BURST PWR METHOD MEAS/USER
Makes adjacent channel power (ACP) measurements
on burst signals.
CAL —
Accesses a menu of calibration functions.
CAL OPN/SHRT AUX CTRL
Measures and computes the average of an open- and a
shorted-input calibration, then stores the data in trace
B and in instrument state register 8.
Table 4-2 Instrument State Functions
Instrument State
Keys
Access Key
Description
To Next Page
