156 6000 Series Oscilloscope User’s Guide
4 Triggering the Oscilloscope
In Asynchronous Mode
1 Press the Baud softkey to select a baud rate of 2.5 Mb/s,
5Mb/s, or 10 Mb/s.
2 Press the Channel softkey to select channel A or B.
In Synchronous Mode
1 Press the FIBEX File softkey to specify the location of the
FIBEX (Field Bus Exchange format) file that defines the
time-triggered timing schedule of the probed FlexRay bus.
2 Press the Channel softkey to select channel A or B.
In Asynchronous or Synchronous Mode In addition to the logic
probe cable connection between the BUSDOCTOR and the
oscilloscope, you must make a LAN connection to allow the
oscilloscope to control the BUSDOCTOR. See also “Specifying
the BUSDOCTOR LAN Address” on page 154.
NOTE
If the BUSDOCTOR 2 loses synchronization, then press the Mode key (in
the BUSDOCTOR 2 Menu) on the oscilloscope to cycle through the modes
and restore synchronization.
NOTE
Before powering-off the oscilloscope, change the BUSDOCTOR 2 mode to
PC.
If oscilloscope power is cycled when in Asynchronous or Synchronous
modes, communication with the BUSDOCTOR 2 will be lost. To restore
communication with the BUSDOCTOR 2 , cycle the BUSDOCTOR 2 power,
wait for its State indicator to turn from red to green, and then press the
Mode key (in the BUSDOCTOR 2 Menu) on the oscilloscope to cycle
through the modes.
