Duration Trigger on a multi-channel pattern whose time duration is less than a value, greater than
a value, greater than a time value with a timeout, or inside or outside of a set of time
values.
Minimum duration setting: 2 ns
Maximum duration setting: 10 s
Nth Edge Burst Trigger on the Nth edge of a burst that occurs after an idle time.
Trigger system (continued)
AutoScale Finds and displays all active oscilloscope and logic (for MSO6000A series MSO)
channels, sets edge trigger mode on highest-numbered channel, sets vertical sensitivity
on oscilloscope channels and thresholds on logic channels, time base to display ~1.8
periods. Requires minimum voltage >10 mVpp, 0.5% duty cycle and minimum frequency
>50 Hz.
Oscilloscope channel triggering
Range (internal) ±6 div from center screen
Coupling AC (~3.5 Hz on MSO/DSO601xA, ~10 Hz on MSO/DSO603xA/605xA/610xA),
DC, noise reject, HF reject and LF reject (~50 kHz)
Logic (D15 - D0) channel triggering (MSO6000A or MSO-upgraded DSO6000A only)
Threshold range (user defined) ±8.0 V in 10 mV increments
Predefined thresholds TTL = 1.4 V, CMOS = 2.5 V, ECL = -1.3 V
External (EXT) triggering
MSO/DSO6xx2A
(2-/2+16-ch models)
MSO/DSO6xx4A
(4-/4+16-ch models)
Input impedance MSO/DSO6012A: 1 MΩ ±3% || 11 pF or 50 Ω
MSO/DSO6032A/6052A/6102A: 1 MΩ ±3% || 14 pF or
50 Ω
MSO/DSO6014A:
1.015 kΩ ±5%
MSO/DSO6034A/6054A/
6104A: 2.14 kΩ ±5%
Maximum input CAT I 300 Vrms, 400 Vpk, CAT II 100 Vrms, 400 Vpk
With 10073C 10:1 probe: CAT I 500 Vpk, CAT II 400 Vpk
5 Vrms with 50-ohm input
±15 V
Range DC coupling: trigger level ± 1V and ± 8V ±5 V
