354 6000 Series Oscilloscope User’s Guide
9 Characteristics and Specifications
Trigger out When “Triggers” is selected (delay ~17 ns; 23 ns for 100 MHz bandwidth models)
0 to 5 V into open circuit
0 to 2.5 V into 50 Ω
When “Source Frequency” or “Source Frequency/8” is selected
0 to 580 mV into open circuit
0 to 290 mV into 50 Ω
Max frequency output:
350 MHz (in Source Frequency mode when terminated in 50 Ω)
125 MHz (in Source Frequency/8 mode when terminated in 50 Ω)
10 MHz ref in/out TTL out, 180 mV to 1 V amplitude with 0 to 2 V offset
Kensington lock Connection on rear panel for security
Power requirements
Line Rating ~Line 120 W max, 96-144 V/48-440 Hz, 192-288 V/48-66 Hz, automatic selection
Environmental characteristics
Ambient temperature Operating –10 °C to +55 °C; non-operating –51 °C to +71 °C
Humidity Operating 95% RH at 40 °C for 24 hr; non-operating 90% RH at 65 °C for 24 hr
Altitude Operating to 4,570 m (15,000 ft); non-operating to 15,244 m (50,000 ft)
Vibration Agilent class B1 and MIL-PRF-28800F; Class 3 random
Shock Agilent class B1 and MIL-PRF-28800F; (operating 30 g, 1/2 sine, 11-ms duration,
3 shocks/axis along major axis. Total of 18 shocks)
Pollution degree2 Normally only dry non-conductive pollution occurs.
Occasionally a temporary conductivity caused by condensation must be expected.
Indoor use Rated for indoor use only
Other
Measurement categories CAT I: Mains isolated
CAT II: Line voltage in appliance and to wall outlet
Regulatory information Safety IEC 61010-1:2001 / EN 61010-1:2001
Canada: CSA C22.2 No. 61010-1:2004
USA: UL 61010-1:2004
Supplementary information The product herewith complies with the requirements of the Low Voltage Directive
73/23/EEC and the EMC Directive 89/336/EEC, and carries the CE-marking accordingly.
The product was tested in a typical configuration with HP/Agilent test systems.
Product specifications, characteristics, and descriptions in this document are subject to
change without notice.
