Characteristics and Specifications 9
6000 Series Oscilloscope User’s Guide 353
Cursors Manually or automatically placed readout of Horizontal (X, DX, 1/DX) and Vertical
(Y, DY). Additionally logic or oscilloscope channels can be displayed as binary or hex
values.
Waveform math One function of 1-2, 1x2, FFT, differentiate, integrate.
Source of FFT, differentiate, integrate: oscilloscope channels 1 or 2, 1-2, 1+2, 1x2.
FFT
Points Fixed at 1000 points
Source of FFT Scope channels 1 or 2 (or 3 or 4 on MSO/DSO6xx4A only), 1+2, 1-2, 1*2
Window Rectangular, flattop, hanning
Noise floor –50 to –90 dB depending on averaging
Amplitude Display in dBV, dBm at 50 Ω
Frequency resolution 0.05/time per div
Maximum frequency 50/time per div
Storage
Save/recall 10 setups and traces can be saved and recalled using internal non-volatile memory
Storage type and format USB 1.1 host ports on front and rear panels
Image formats: BMP (8-bit), BMP (24-bit), PNG (24-bit)
Data formats: X and Y (time/voltage) values in CSV format, ASCII XY format, BIN format
Trace/setup formats: Recalled
I/O
Standard ports USB 2.0 high speed device, two USB 1.1 host ports, 10/100-BaseT LAN, IEEE488.2 GPIB,
XGA video output
Max transfer rate IEEE488.2 GPIB: 500 kbytes/sec
USB (USBTMC-USB488): 3.5 Mbytes/sec
100 Mbps LAN (TCP/IP): 1 Mbytes/sec
Printer compatibility Selected HP Deskjet and Officejet printers
General characteristics
Physical size 35.4 cm wide x 18.8 cm high x 28.2 cm deep (without handle)
39.9 cm wide x 18.8 cm high x 28.2 cm deep (with handle)
Weight Net: 4.9 kgs (10.8 lbs)
Shipping: 9.4 kgs (20.7 lbs)
Probe comp output Frequency ~1.2 kHz, Amplitude ~2.5 V
