Agilent X-Series Signal Generators User’s Guide 241
Basic Digital Operation (Option 653/655/656/657)
Waveform Licensing
Table 8-6 Waveform Licensing Slot Status Messages
Status Column Meaning Notes
Available The slot has never had a waveform
added to it.
50 slots are initially available for
each Option 25x.
5 slots are initially available for
each Option 22x.
Locked MM/DD/YY The slot is locked and can no
longer be modified.
The waveform in this slot is
licensed to this signal generator
for unlimited playback.
Remaining Trial Time HH:MM The slot is in a trial period that is
available for 48 hours that begins
when a waveform is added.
During the trial period, the
waveform in this slot can be
played, cleared, or replaced with
another waveform.
Lock Required The trial period for the slot has
expired but the slot has not been
locked.
The slot can be cleared or
replaced with a different waveform
but the waveform cannot be played
until the slot is locked. A trial
period is no longer available.
