Mirror CLI Command Structure
Figure 67 displays the CLI command structure to configure mirroring parameters. The mirror
destination commands are configured under the
config>mirror context. The mirror source
commands are configured under the
debug>mirror-source context. The mirror destination
configuration includes configuring the 7750 SR router with the sniffer to accept remote mirror
sources and configuring the mirror service on the mirror source 7750 SR router for remote
mirroring.
Figure 1: Mirror CLI Configuration Context
ROOT
MIRROR
MIRROR SOURCE
CONFIG
MIRROR DESTINATION
SAP
SDP - for (outbound) remote mirroring
REMOTE SOURCE - for (inbound) remote mirroring
SAP
DEBUG
PORT
IP FILTER
MAC FILTER
INGRESS LABEL
FAR-END
SERVICE
SDP
SHOW
MIRROR
MIRROR-DESTINATION
