The sap-id can be configured in one of the following formats:
Values sap-id:null[port-id | bundle-id | lag-id | aps-id]
dot1q [port-id | bundle-id | lag-id | aps-id]:qtag1
qinq [port-id | bundle-id | lag-id]:qtag1.qtag2
atm [port-id | bundle-id][:vpi/vci | vpi | vpi1.vpi2]
frame [port-id | bundle-id]:dlci
cisco-hdlc slot/mda/port.channel
ima-grp bundle-id[:vpi/vci | vpi | vpi1.vpi2]
Type Syntax Example
port-id slot/mda/port[.channel]6/2/3.1
null [port-id | bundle-id | lag-id | aps-id] port-id: 6/2/3
bundle-id: bundle-ima-10/1.1
bundle-ppp-10/1.1
lag-id: lag-100
aps-id: aps-1
dot1q [port-id |
bundle-id | lag-id | aps-id]:qtag1 port-id:qtag1: 6/2/3:100
bundle-id:qtag1: bundle-ima-10/1.1:16
bundle-id:qtag1: bundle-ppp-10/1.1:16
lag-id:qtag1: lag-100:102
aps-id:qtag1: aps-1:103
qinq [port-id | bundle-id | lag-id]:qtag1.qtag2 port-id:qtag1.qtag2: 6/2/3:100.10
bundle-id:qtag1.qtag2: bundle-ima-10/1.1:16.17
bundle-ppp-10/1.1:16.17
lag-id:qtag1.qtag2: lag-100:
bundle-id:qtag1.qtag2: bundle-ima-5/1.1:100.10
bundle-ppp-5/1.1:100.10
atm [port-id | aps-id][:vpi/vci|vpi|vpi1.vpi2] port-id: 9/1/1:100/100
aps-id: aps-1
vpi/vci: 16/60
vpi: 16
vpi1.vpi2: 16.200
frame-relay [port-id | aps-id]:dlci port-id: 9/1/1:100
aps-id: aps-1
dlci: 16
cisco-hdlc slot/mda/port.channel port-id: 2/2/3.1
ima-grp bundle-id[:vpi/vci | vpi | vpi1.vpi2] bundle-type-slot/mda.bundle-num: bundle-ima-10/1.1:16
bundle-ppp-10/1.1:16
vpi/vci: 16/60
vpi: 16
vpi1.vpi2
: 16.200
