Show Commands
Page 1364 7750 SR OS Services Guide
218 Mirror Up Down 1 04/20/2006 13:49:57
318 Mirror Down Down 1 04/20/2006 13:49:57
319 Mirror Up Down 1 04/20/2006 13:49:57
320 Mirror Up Down 1 04/20/2006 13:49:57
1000 Mirror Down Down 1 04/20/2006 13:49:57
1216 Mirror Up Down 1 04/20/2006 13:49:57
1412412 Mirror Down Down 1 04/20/2006 13:49:57
-------------------------------------------------------------------------------
Matching Services : 7
-------------------------------------------------------------------------------
===============================================================================
A:ALA-48#
mirror mirror-dest
Syntax mirror mirror-dest service-id
Context show
Description Displays mirror configuration and operation information.
Parameters service-id — Specify the mirror service ID.
Output Mirroring Output — The following table describes the mirroring output fields:
Table 1: Mirroring Output Fields
Label Description
Service Id
The service ID associated with this mirror destination.
Type
Entries in this table have an implied storage type of 'volatile'.
The configured mirror source information is not persistent.
Admin State
Up — The mirror destination is administratively enabled.
Down — The mirror destination is administratively disabled.
Oper State
Up — The mirror destination is operationally enabled.
Down — The mirror destination is operationally disabled.
Forwarding
Class
The forwarding class for all packets transmitted to the mirror destination.
Remote
Sources
Yes — A remote source is configured.
No — A remote source is not configured.
Slice
The value of the slice-size, i.e., the maximum portion of the mirrored frame
that will be transmitted to the mirror destination. Any frame larger than the
slice-size will be truncated to this value before transmission to the mirror
destination. A value of 0 indicates that mirrored packet truncation based on
slice size is disabled.
