VPRN Show Commands
7750 SR OS Services Guide Page 1873
Sample Output
*A:ALA-12# show router 3 rip neighbor
==============================================================================
RIP Neighbors
==============================================================================
Interface Adm Opr Primary IP Send Recv Metric
Mode Mode In
------------------------------------------------------------------------------
router-2/1 Up Up 10.0.3.12 None Both 1
router-2/2 Up Up 10.0.5.12 BCast Both 1
router-2/3 Up Up 10.0.6.12 BCast Both 1
router-2/4 Up Up 10.0.10.12 BCast Both 1
router-2/5 Up Up 10.0.9.12 BCast Both 1
router-2/6 Up Up 10.0.17.12 None Both 1
router-2/7 Up Up 10.0.16.12 None Both 1
==============================================================================
*A:ALA-12#
Detailed Show RIP Neighbor Output — The following table describes the standard command
output fields for a RIP group.
RIPv1 — Specifies that RIP updates in version 1 format only will be
accepted.
RIPv2 — Specifies that RIP updates in version 2 format only will be
accepted.
Metric In
The metric added to routes received from a RIP neighbor.
Label Description
Neighbor
The RIP neighbor name.
Description
The RIP neighbor description. No Description Available indi-
cates no description is configured.
Primary IP
The RIP neighbor interface primary IP address.
Group
The RIP group name of the neighbor interface.
Admin State
Down — The RIP neighbor interface is administratively down.
Up — The RIP neighbor interface is administratively up.
Oper State
Down — The RIP neighbor interface is operationally down.
Up — The RIP neighbor interface is operationally up.
Send Mode
Bcast — Specifies that RIPv2 formatted messages are sent to the
broadcast address.
Mcast — Specifies that RIPv2 formatted messages are sent to the
multicast address.
Label Description
