Alesis Fusion Reference Manual

A Effects and Implementation
263
Master EQ Effects Parameters
Parameter Default Range Low Range High
Low Freq: 153.59 kHz 20 Hz 1000.00 Hz
Low Gain: 0.0 dB 18.0 18.0
Low Mid Freq 557.28 Hz 300 Hz 10.00 kHz
Low Mid Gain 0.0 dB 18.0 18.0
Low Mid Q 1.00 .50 4.00
High Mid Freq 1.53 kHz 300 Hz 10.00 kHz
High Mid Gain 0.0 dB 18.0 18.0
High Mid Q 1.00 .50 4.00
High Freq 3.96 kHz 500 Hz 10.00 kHz
High Gain 0.0 dB 18.0 18.0

Alesis Fusion Specifications

General

Type	Workstation
Polyphony	64 voices
Synthesis Types	Sample Playback, Virtual Analog, FM, Physical Modeling
Display	240 x 128 pixel LCD
MIDI	In, Out, Thru
RAM	64MB (expandable to 192MB)
Weight (61-key)	28 lbs
Keyboard	61 or 88 keys
Keyboard Type	Semi-weighted (61-key), Hammer action (88-key)
Effects	Reverb, Chorus, Delay, Flanger, Phaser, Distortion, EQ
Storage	40GB internal hard drive
Sampling	Yes
Inputs	2 x 1/4" inputs, 1 x XLR
Outputs	4 x 1/4" outputs, 1 x Headphone
