Alesis Fusion Reference Manual

3
Chapter 3: Fusion Modes
94
Menu: Program/Synth/Envelope
Parameter: Release
Value Range: 0 – 30 Sec
This sets the amount of time the envelope will take to get from its
current level to zero after the note has been released. The higher the
value, the longer it will take.
Menu: Program/Synth/Envelope
Parameter: Overlap Release
Value Range: None, 1.002 ms – 30 Sec
If you play a note and trigger it a second time, the first instance of that
note goes into “overlap release” state and decays at whatever time
defined in this parameter. This parameter can be used to efficiently steal
voices in order to make better use of the Fusion’s DSP (which ultimately
leads to higher polyphony count).
If set to “none” both voices (or however many voices you have
repeatedly triggered) will release as normal.
Menu: Program/Synth/Envelope
Parameter: Del Env
Value Range: Yes, No
This button deletes the currently selected Envelope. A dialog box (see
above) will appear asking you to confirm whether you want to delete
your envelope. Press “Yes” to delete.

Alesis Fusion Specifications

General

Type	Workstation
Polyphony	64 voices
Synthesis Types	Sample Playback, Virtual Analog, FM, Physical Modeling
Display	240 x 128 pixel LCD
MIDI	In, Out, Thru
RAM	64MB (expandable to 192MB)
Weight (61-key)	28 lbs
Keyboard	61 or 88 keys
Keyboard Type	Semi-weighted (61-key), Hammer action (88-key)
Effects	Reverb, Chorus, Delay, Flanger, Phaser, Distortion, EQ
Storage	40GB internal hard drive
Sampling	Yes
Inputs	2 x 1/4" inputs, 1 x XLR
Outputs	4 x 1/4" outputs, 1 x Headphone
