Chapter 3: Fusion Modes
3
43
Menu: Program/Program/Output
Parameter: Bus Send 1 & 2 (The effect is listed in the parenthesis
to the right of each Bus Send parameter)
Value Range: 0 – 100%
Bus Effects, unlike Insert Effects are shared by every program, mix, and
song on the Fusion. There are two Bus Effects available, labeled “Bus
Send 1” and “Bus Send 2.”
Dial in the amount of processing you want from each Bus Effect. For
instance, if Bus Effect 1 is a reverb, 0% will have no effect on the
program, whereas 100% will yield the maximum amount of reverb which
will sound like a washy, indistinct sound. With most Bus Sends
(including reverbs), a medium setting will yield the best results.
Note that these settings affect the MAIN outputs only. If you set your
program to output on the AUX output (see below), the program will
bypass all bus effects.
Menu: Program/Program/Output
Parameter: Output Bus
Value Range: Main, Aux, None
The program’s audio output can be played through either the MAIN or
AUX outputs or disabled completely by setting this parameter to NONE.
Keep in mind that your sends are prior to the output selection. So if a
program has sends to an effect and the output set to MAIN then the user
hears the program + effect on the main outputs and nothing on the Aux
outputs. If the output setting is set to AUX then the user hears program
on the Aux and all “wet” effect output on the mains. If the output is set
to NONE, then the user hears all “wet” effect on the main outputs and
nothing on the Aux outputs. A setting of NONE is useful if the user
wants just the effect output without hearing the actual program output.
Also note that the effects bus return volume (on the effects page) must
be turned up in order to hear the effect. The diagram on page 262
should clear up any confusion.
Menu: Program/Program/Output
Parameter: Jump Mod
Value Range: (none)
Once you have created a modulation route to a parameter on this page
(using the modulation matrix), a new button called “Jump Mod” appears
on the right that allows you to immediately jump to the page of the
matrix where the connection is being made.
Selecting Effects:
To select which effects you’d like to use, go
to the Effects/Bus/Select menu (see page 253
for more about this).
