Specifications
291
Sound Engine
Sound Generation: Dual TI processors
Polyphonic Voices: Varies depending on type of program loaded.
Basic programs using minimal oscillators, filters,
and envelopes play back the following number of
voices on each engine (the Fusion has two voice
engines in total):
Sample playback: 136 voices (272 total)
FM: 120 voices (240 total)
Virtual Analog: 70 voices (140 total)
Physical Model (Reed): 30 voices (60 total)
Physical Model (Wind): 24 voices (48 total)
Program Memory: Programs can be stored on the Fusion’s internal
memory, hard disk, or compact flash cards giving
you virtually unlimited storage for your programs.
The workstation ships with the following:
384 Preset programs
24 Drum kits
128 General MIDI programs (with 8 drum kits)
128 Mixes
Effects: 57 Insert Effects
64 Bus Effects
4 Band Master EQ (low shelf, low,
mid, high mid, Hi shelve)
Sampling Inputs
(Using Minimum Gain)
Connectors: 2 Balanced ¼” TRS jacks
Input Impedance: 100 kΩ
Gain Trim Range: 0dB to 21dB
Signal To Noise Ratio: 102dB typ A-weighted
THD+N: 0.005% typ @ -1dBFS/1KHz
Frequency Response: +/-0.05 dB, 20-20KHz
Maximum Input Level: 3dBV
Multitrack Inputs
Connectors: 8 Balanced ¼” TRS jacks
Input Impedance: 16 kΩ
(+4dBu setting)
Signal To Noise Ratio: 107dB typ A-weighted
THD+N: 0.005% typ @ -1dBFS/1KHz
Frequency Response: +/-0.15 dB, 20-20KHz
Maximum Input Level: 19dBu
(-10dBV setting)
Signal To Noise Ratio: 104dB typ A-weighted
THD+N: 0.005% typ @ -1dBFS/1KHz
Frequency Response: +/-0.15 dB, 20-20KHz
Maximum Input Level: 6dBV
About these measurements:
All measurements done over a 20Hz – 20kHz
range with a 1kHz sine wave at -1dBFS
input.
These measurements were done under real-
world conditions using a production model
of the Fusion. The performance on your unit
should be similar to what is listed here.
