3
Chapter 3: Fusion Modes
78
The Reed Physical Model:
The following diagram describes the Fusions Reed Model. In it, you’ll
notice three distinct groups of parameters including “Breath,” “Reed,
and “Bore.” Each group makes up a different portion of the physical
model and these groups interact with one another to create the overall
sound that you hear.
The “Breath” parameters model the performer blowing into the
instrument, while the “Reed” parameters model the mouthpiece of the
instrument that is being played. Finally, the “Bore” parameter models
the body of the instrument.
Why Can’t I Hear Anything?
Since Physical Modeling creates a
mathematical model of a “real world”
instrument, it is possible to set your
Synth/Model menu settings in a way where
no sound or unmusical tones (or noise) will
be synthesized. This is analogous to either
playing a physical instrument incorrectly or
building an instrument that is incapable of
creating musical tones. If you adjust a
parameter and your program doesn’t make
any sound (or you only hear strange noises
and tones), this is not an error. You’ve
probably just pushed the physical model into
unmusical territories. If this happens, scale
back the parameter you were editing until
you start hearing musical tones again.
Breath
Pressure, Noise
Reed
Threshold, Slope, Curve
Output
Bore
Frequency, Mix,
Gain, Filter
To Filter

Table of Contents

Other manuals for Alesis Fusion

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Alesis Fusion and is the answer not in the manual?

Alesis Fusion Specifications

General IconGeneral
TypeWorkstation
Polyphony64 voices
Synthesis TypesSample Playback, Virtual Analog, FM, Physical Modeling
Display240 x 128 pixel LCD
MIDIIn, Out, Thru
RAM64MB (expandable to 192MB)
Weight (61-key)28 lbs
Keyboard61 or 88 keys
Keyboard TypeSemi-weighted (61-key), Hammer action (88-key)
EffectsReverb, Chorus, Delay, Flanger, Phaser, Distortion, EQ
Storage40GB internal hard drive
SamplingYes
Inputs2 x 1/4" inputs, 1 x XLR
Outputs4 x 1/4" outputs, 1 x Headphone
