1756-6.5.3 - December 1999
PLC-5C to Logix5550 Controller: Scheduled Communications 8-11
The Module Properties window will appear.
3. Enter the following parameters:
4. Click on Finish to accept the configuration of the 1756-CNB module.
The Local_CNB module will appear indented under the I/O
Configuration folder.
5. Right-click on the Local_CNB module and select New Module.
Name Local_CNB
Slot 1
Electronic Keying Compatible Module
