1756-6.5.3 - December 1999
8-12 PLC-5C to Logix5550 Controller: Scheduled Communications
The Select Module Type window will appear.
6. Select the 1785-PLC5C module and click on OK.
The Module Properties window will appear:
7. Enter the following parameters:
8. Click on the Finish button to accept the configuration.
Name Producer
Node 11
