1756-6.5.3 - December 1999
8-16 PLC-5C to Logix5550 Controller: Scheduled Communications
The following pop-up window will appear.
7. Select Edit Tag Properties.
The New Tag configuration window will appear:
8. Enter the following parameters:
Name PLC5_data
Tag Type Consumed
Controller PRODUCER
Remote Instance
1
(1)
(1)
The Remote Instance must match the Message Number assigned by
RSNetWorx for ControlNet.
Data Type Consumed_data
RPI
5ms
(2)
(2)
Remember that the RPI cannot be faster than the NUT. See page 1-7.
