1756-6.5.3 - December 1999
10-10 Controlling I/O Over a ControlNet Network
The Module Properties window will appear.
7. Enter the following parameters:
8. Click on the Finish button to accept the configuration.
The I/O Configuration in the Project window should look similar to the
one shown below.
Name Remote_Digital_Output
Slot 3
Comm Format Rack Optimization
Electronic Keying Compatible Module
If you want to alter the default parameters, click on Next. Refer to the
ControlLogix Digital I/O User Manual, publication 1756-6.5.8, for details.
