Chapter 5 Parameter Introductions
100
Setting Function
Setting Function
6 RST: reset 7 FC: Setting frequency selection
8 FJOG: JOG FWD 9 RJOG: JOG REV
10 UP 11 DOWN
12 UP/DOWN Reset 13 FRE: Coast-to-stop
14
Forced outage (according to
Dec time4)
15 DC injection braking
16 Acc/Dec prohibit 17 Inverter running prohibit
18 S1 Multi-step Speed 1
19
S2 Multi-step Speed 2
20 S3 Multi-step Speed 3
21
S4 Multi-step Speed 4
22 S5 Multi-step Speed 5
23
S6 Multi-step Speed 6
24 S7 Multi-step Speed 7
25
Command channel switch to
Terminal control 2
26 SS1 Multi-step Speed 27 SS2 Multi-step Speed
28 SS3 Multi-step Speed 29 SS4 Multi-step Speed
30 T1 Acc/Dec time 1 31 T2 Acc/Dec time 2
32 T3 Acc/Dec time 3 33 T4 Acc/Dec time 4
34 TT1 Acc/Dec time 35 TT2 Acc/Dec time
36 Forced outage normally close 37
EH0: External fault signal
normally open
38
EH1: External fault signal
normally close
39
EI0: External interrupt signal
normally open
40
EI1: External interrupt signal
normally close
41 Switch to keyboard control
42 Start PLC operation 43 Pause the PLC operating
44 Reset PLC stop status 45
Start wobble frequency
operation
46
Reset the wobble frequency
operating status
47 Start PID operation
48 Reserved 49 Timing drive input
50 Counter trig signal input 51 Counter clear
52 Actual Length clear 53 Timing scale selection
54
EH2 External fault rising edge
valid
55
EH3 External fault falling edge
valid
56~65 Reserved
66
PUL: Pulse input (if two
inputs appear:
3004GB/35R5PB and below is
decided by X4;
35R5GB/37R5PB and above is
decided by X7 )
67
Single-phase speed measuring
input (if two inputs appear:
3004GB/35R5PB and below is
decided by X4;
35R5GB/37R5PB and above is
decided by X7)
