Alpha 6000 - A Trial Run; Operation Modes Switching of Inverter

Chapter 3 Operation
50
Switch of operation modes of this series inverter are as figure 3-8 description:
Operation mode of
inverter
JOG active
PID termianl
active
Wobble frequency
running terminal
active
PLC termianl
active
PID running
Wobble frequency
running
PLC running
Termianl function:
FC frequency
setting active
Common running
NO
NO
NO
NO
NO
END
YES
Running according to
P0.01 selection
JOG running
Y
E
S
Y
E
S
YE
S
YE
S
Figure 3-8 Operation modes switching of inverter
3.3.4 A Trial Run
Please wire the main circuit and control circuit strictly according to the technology
requirement provided by the user manual when the inverter is ready for operation, turn
ON the power supply. Verify that the inverter powers up properly. If any problems are
detected, turn OFF the power supply immediately.
When the keyboard displays the output frequency, the inverter is initialized. If the
keyboard is not connected right, the keyboard will display the fault code “CCF2” after 5
seconds. Please connect the keyboard again.
