P3.15 Terminal Y2 function definition
Range: 0~30【2】
P3.16 Output function of Relay 1 (TA/TB/TC)
Range: 0~30【19】
P3.17 Output function of Relay 2
(BRA/BRB/BRC)
Range: 0~30【0】
Note:
For model 3004GB/35R5PB and below, function code P3.14, P3.15 are reserved and
cannot been modified. At the same time, output function No. 26 and 27 are reserved ,
there is no output; Function code P3.17 is used for “the terminal output hold time
setting of fixed-length arriving”. The details are below:
 This series inverter has 5 digital outputs (For model 3004GB/35R5PB and bellow,
there are two digital outputs (DO and Relay 1)) only. The multi-function output
terminals, D0, Y1, Y2, Relay 1, and Relay 2 are programmable. They can be
selected to output some controlling and monitoring signal according to the
application requirement. Refer to Table 5-3-5.
 If collectors are selected as PLC running steps output or fault output (only
35R5GB/37R5PB and above can be set), D0, Y1, Y2 must be selected as the same
function (26, or 27) to make the combination effective.
 Fault type and running steps refer to Table 5-3-4.
Table 5-3-4 Fault Type and Running Step
TA Y2 Y1 D0
Fault
Type
Meaning Steps
OFF
OFF OFF ON OC Over-Current T1
OFF
OFF ON OFF SC Short Circuit T2
OFF
OFF ON ON OU Over Voltage T3
OFF
ON OFF OFF Uu1 Under Voltage T4
OFF
ON OFF ON OH1 Overheat T5
OFF
ON ON OFF OL2 Inverter Overload T6
OFF
ON ON ON EH External Fails T7
ON OFF OFF OFF - - T8
ON OFF OFF ON - - T9
ON OFF ON OFF - - T10
ON ON OFF OFF - - T12
ON ON OFF ON - - T13
ON ON ON OFF - - T14
ON ON ON ON - - T15
