Alpha 6000 - P1: Start;Stop Control

Chapter 4 Parameter Index
56
Function
code
Function Name Range of settings Default Change
MODBUS
Address
P0.19 Control mode
0.0: Magnetic flux vector control
0.1~30.0%: Manual torque boost
3004GB/35
R5PB or
below:
4.0%
35R5GB/37
R5PB or
above:
0.0%
○ 0113
P0.20
Cut-off point
used for manual
torque boost
0.00~50.00Hz 16.67Hz ○ 0114
P0.21 Acc time1
3132G/3160P or below:
0.1~3600s
3160G/3185P or above :
1.0~3600s
3022G/303
0P or
below:6.0s;
3030G/303
7P or
above :
20.0s
○ 0115
P0.22 Dec time1 ○ 0116
P1: Start/Stop Control
Function
code
Function Name Range of settings Default Change
MODBUS
Address
P1.00 Starting mode
0: Start directly
1: Brake first and then start at start
frequency
2: Start after speed tracking (the mode
is only valid for the motor of
35R5GB/37R5PB or above)
Note: the startup includes power on,
power recovery after an instantaneous
off, external fault reset, and restart
after coast to stop.
0 ○ 0200
P1.01 Starting frequency 0.10~60.00Hz 0.50Hz ○ 0201
P1.02
Starting frequency
holding time
0.0~10.0s 0.0s ○ 0202
P1.03
DC injection
braking current at
start
Type G: 0.0~100.0% of inverter rated
current
Type P: 0.0~80.0% of inverter rated
current
0.0% ○ 0203
P1.04
DC injection
braking time at
start
0.0~30.0s 0.0s ○ 0204
P1.05 Acc/Dec mode
0: Linearity
1: S-curve
2: (Reserved)
3: (Reserved)
0 ○ 0205
P1.06
Time of S-curve
initial
10.0~50.0% (Acc/Dec Time)
P1.06+P1.07≤90%
20.0% ○ 0206
