Alpha 6000 - P4: Analog and Pulse Function

Chapter 4 Parameter Index
66
P4: Analog and Pulse Function
Function
code
Function Name Range of settings Default Change
MODBUS
Address
P4.00
Analog Nonlinear
Selection
0:None 1:AI1
2:AI2 3: Pulse
0 × 0500
P4.01
Min analog value
Input 1 (AI1
Terminal)
0.00~P4.03 0.10V ○ 0501
P4.02
Physical value 1
corresponding to
Min analog value
Input
0.0~100.0% 0.0% ○ 0502
P4.03
Max analog value
Input 1 (AI1
Terminal)
P4.01~10.00V 10.00V ○ 0503
P4.04
Physical value 1
corresponding to
Max analog value
Input
0.0~100.0% 100.0% ○ 0504
P4.05
Analog input filter
time constant 1
(AI1 Terminal)
0.01~50.00s 0.05s ○ 0505
P4.06
Min analog value
Input 2 (AI2
Terminal)
0.00~P4.08 0.10V ○ 0506
P4.07
Physical value 2
corresponding to
Min analog value
Input
0.0~100.0% 0.0% ○ 0507
P4.08
Max analog value
Input 2 (AI2)
P4.06~10.00V 10.00V ○ 0508
P4.09
Physical value 2
corresponding to
Max analog value
Input
0.0~100.0% 100.0% ○ 0509
P4.10
Analog input filter
time constant 2
(AI2 Terminal)
0.01~50.00s 0.05s ○ 050A
P4.11
Min pulse value
Input 3 (pulse
input Terminal)
0.00~P4.13 0.00k ○ 050B
P4.12
Physical value 3
corresponding to
Min pulse value
Input
0.0~100.0% 0.0% ○ 050C
P4.13
Max pulse value
Input 3 (pulse
Input Terminal)
P4.11~50.00k 50.00k ○ 050D
