Chapter 3 Operation
41
Table 3-1 The LED monitoring objects
Set
value
Monitoring object(Unit)
Permission of Modify
in running state
PC.01=1 Output frequency before compensation (Hz)
PC.02=1 Actual output frequency (Hz)
PC.03=1 Output current (A)
PC.04=1 Setting frequency (Hz blink) permission
PC.05=1 Motor rotate speed (r/min)
PC.06=1 Setting speed (r/min blink) permission
PC.07=1 Running linear speed (m/s)
PC.08=1 Setting linear speed (m/s blink)
PC.09=1 Output power (no unit)
PC.10=1 Output torque(%)
PC.11=1 Output voltage (V)
PC.12=1 Bus voltage (V)
PC.13=1 AI1 (V)
PC.14=1 AI2 (V)
PC.15=1 Analogy PID feedback (no unit)
PC.16=1 Analogy PID feed (no unit) permission
PC.17=1 Extern count value (no unit)
PC.18=1 State of terminal (no unit)
PC.19=1 Actual length(m)
3.1.2 Description of Keystroke Function
On the inverter keyboard, there are nine keystrokes. In addition, the function of each
keystroke is defined as table 3-2.
