Alpha 6000 - Commissioning of Keyboard; Flow Chart of the Inverter Initialization

Chapter 3 Operation
51
Operation process of power up the inverter is as the following:
wiring is
right.
wiring as the
requirement stated
in this manual
Power ON
see output
frequency
monitor: 0.00Hz
Power on failed
Disconnect the power
input air switch.
Check the reason
heard the sound of
contactor indraft?
Display fault
code"CCF2"or no
disolay
YES
NO
YES
NO
YES
YES
Start
NO
NO
POWER ON
sucsessful
the input
voltate is right
Figure 3-9 Flow chart of the inverter initialization
3.4 Commissioning of Keyboard
Assume that the inverter need to run forward at 30.00 Hz at first, then run reverse at the
same frequency,
