Alpha 6000 - Multifunction Input Selection

Chapter 5 Parameter Introductions
99
 Open is valid: Signal is disabled if the control terminal and COM terminal are
short-circuited. Normally open and normally close are not limited.
For models which power is equal or below 3004GB/35R5PB:
P3.01 Multi-function input selection Terminal X1
Range: 0~65【1】
P3.02 Multi-function input selection Terminal X2
Range: 0~65【2】
P3.03 Multi-function input selection Terminal X3
Range: 0~65【37】
P3.04 Multi-function input selection Terminal X4
Range: 0~69【26】
P3.05 Multi-function input selection Terminal X5
Range: 0~69【27】
For models which power is equal or above 35R5GB/37R5PB:
P3.01 Multi-function input selection Terminal X1
Range: 0~65【1】
P3.02 Multi-function input selection Terminal X2
Range: 0~65【2】
P3.03 Multi-function input selection Terminal X3
Range: 0~65【37】
P3.04 Multi-function input selection Terminal X4
Range: 0~65【26】
P3.05 Multi-function input selection Terminal X5
Range: 0~65【27】
P3.06 Multi-function input selection Terminal X6
Range: 0~65【28】
P3.07 Multi-function input selection Terminal X7
Range: 0~69【0】
P3.08 Multi-function input selection Terminal X8
Range: 0~69【0】
Note:
 For models which power is equal or below 3004GB/35R5PB, only X1~X5 is
valid, function code P3.06~P3.08 can not be modified; but P3.04, P3.05 (X4, X5
terminal, 3004GB/35R5PB and below) will be the same as P3.07, P3.08 (X7, X8
terminal, 35R5GB/37R5PB and above), the setting range is from 0 to 69;
 Control terminals X1~X8 are multi-function terminals. They can be defined by
preset P3.01~P3.08, which are allowed function redefined. The redefined function
terminal, if one of them is valid, the function is effective. For the details of settings
and functions of P3.01~P3.08, refer to Table 5-3-1.
Table 5-3-1 Multifunction input selection
Setting Function Setting Function
0 NULL: No defined 1 FWD: Running Forward
2 REV: Running Reverse 3 RUN
4 F/R: Running direction 5 HLD: self-hold selection
