Chapter 4 Parameter Index
54
Chapter 4 Parameter Index
Attention:
“○”means that the parameters can be changed during inverter running and stop state;
“×”means that the parameters cannot be changed during running;
“*” means that the actually measured value or fixed parameters cannot be changed;
“-” means that the parameters can be only set by the manufacturer and cannot be
changed by the user.
P0: Basic function
Function
code
Function Name Range of settings Default Change
MODBUS
Address
P0.00
Reference
frequency
0 ~ Maximum frequency 0.00Hz ○ 0100
P0.01
Frequency
setting 1
0: NULL
1: Set by keyboard digital encoder
2: Terminal AI1
3: Terminal AI2
4: Pulse input
5: Serial communication
6: MS (Multi-step) Speed
7: Terminal UP/DOWN
8: PLC
9: PID
10: Wobble frequency operating
1 × 0101
P0.02
Frequency
setting 2
Ibid, 0~6 0 × 0102
P0.03
Frequency
setting selection
0: Frequency setting 1
1: Terminal Selection
2: Frequency setting 1+ Frequency
setting 2
3: | Frequency setting 1- Frequency
setting 2 |
4: Min (Frequency setting 1,
Frequency setting 2)
5: Max (Frequency setting 1,
Frequency setting 2)
0 × 0103
P0.04
Run command
mode selection
0: Keyboard control
1: Terminal control 1(STOP invalid)
2: Terminal control
2(STOP valid)
3: Serial communication 1(STOP
invalid)
4: Serial communication 2(STOP
valid)
5: Terminal control 3 (STOP and
JOG invalid)
0
× 0104
