P3: I/O Terminal control
This page only for 3004GB/35R5PB and below
Function
code
Function Name Range of settings Default Change
MODBUS
Address
P3.00
Terminal
function mode
0: Close valid
1: Open valid (Normally open /close is
not limited.)
0 × 0400
P3.01
Multi-function
input selection
Terminal X1
0: NULL, No defined
1: FWD: Running Forward
2: REV: Running Reverse
3: RUN
4: F/R running direction
5: HLD self-hold selection
6: RST reset
7: FC Setting frequency selection
8: FJOG(JOG FWD)
9: RJOG(JOG REV)
10: UP
11: DOWN
12: UP/DOWN Reset
13: FRE Coast-to-stop
14: Forced outage (According to Dec
time4)
15: DC injection braking
16: Acc/Dec prohibit
17: Inverter running prohibit
18: S1 Multi-step Speed 1
19: S2 Multi-step Speed 2
20: S3 Multi-step Speed 3
21: S4 Multi-stepSpeed 4
22: S5 Multi-step Speed 5
23: S6 Multi-step Speed6
24: S7 Multi-step Speed7
25: Command channel switch to Terminal
control 2
26: SS1 Multi-step Speed
27: SS2 Multi-step Speed
28: SS3 Multi-step Speed
29: SS4 Multi-step Speed
30: T1 Acc/Dec time1
31: T2 Acc/Dec time2
32: T3 Acc/Dec time3
33: T4 Acc/Dec time4
34: TT1 Acc/Dec time1
35: TT2 Acc/Dec time1
36: Force stop normally close
37: EH0: External fault signal normally
open
38: EH1: External fault signal normally
close
39: EI0: External interrupt signal
normally open
40: EI1: External interrupt signal
normally close
1 × 0401
P3.02
Multi-function
input selection
Terminal X2
2 × 0402
